Fast Track Populated I/O Plate — JRE D3-PEM-LAN10G-USB3
Type D Fast Track plate with USB3-1 and RJ-45 10G filtering, a PEM-1 mains entry module, and 2 SMA Female bulkheads.
JRE D3-PEM-LAN10G-USB3 specifications
- Part Number
- D3-PEM-LAN10G-USB3
- SMA Connectors
- 2 SMA Female bulkhead connectors
- Filtered Interface
- 1 Dual Filtered interface with USB3-1 and RJ-45 10G Ethernet filters
- Power Entry
- 1 PEM-1 Filtered mains power entry module
- Plate Size
- Type "D" I/O plate
JRE D3-PEM-LAN10G-USB3 overview
When both the Ethernet and USB sides of the DUT call for their high-speed filtered interfaces, this populated plate keeps them together. A filtered mains entry and two SMA bulkheads round out a dense Type D configuration for data, power, and RF.
- 1 Dual Filtered interface with USB3-1 and RJ-45 10G Ethernet filters
- High-speed data paths discriminating differential signals from common-mode RF
- 1 PEM-1 Filtered mains power entry module for the powered DUT setup
- 2 SMA Female bulkhead connectors for controlled RF connections
- In-stock Type D plate that can be changed in the field
The $1,335.00 price is for the populated combination, ready to pair with an in-stock enclosure for delivery in days. I'd reserve this dense configuration for a test that will use both high-speed data paths, mains power, and the RF pair. Every populated crossing should earn its place.
