Fast Track Populated I/O Plate — JRE D3-PEM-LAN-USB3
Type D Fast Track plate with USB3-1 and RJ-45 filtering, a PEM-1 mains entry module, and 2 SMA Female bulkheads.
JRE D3-PEM-LAN-USB3 specifications
- Part Number
- D3-PEM-LAN-USB3
- SMA Female bulkhead connectors
- 2
- Filtered interface
- 1 Dual Filtered interface with USB3-1 and RJ-45 Ethernet filters
- Power entry module
- 1 PEM-1 Filtered mains power entry module
- Compatible plate size
- Type "D" I/O plate
- Compatible enclosure example
- JRE 1724A
JRE D3-PEM-LAN-USB3 overview
The reason to choose this plate is USB3 within a ready-populated Type D layout, not a generic preference for more speed. I recommend it when wired Ethernet, filtered mains power, and two SMA RF paths also belong in the same setup.
- 1 Dual Filtered interface with USB3-1 and RJ-45 Ethernet filters
- USB3-1 path discriminating differential data from common-mode RF
- 1 PEM-1 Filtered mains power entry module for the internal load
- 2 SMA Female bulkhead connectors for bringing RF signals through the wall
- In-stock Fast Track assembly that remains field-replaceable
The $1,220.00 price covers the ready-populated combination, and pairing it with an in-stock enclosure can support delivery in days. This plate is the right shortcut only when USB3, LAN, mains power, and both RF paths belong in the plan. If the DUT does not require USB3, a USB2-populated Type D plate may be the more direct fit.
