Fast Track Populated I/O Plate — JRE D3-PEM-LAN10G-USB2
Type D Fast Track plate with USB2 and RJ-45 10G filtering, a PEM-1 mains entry module, and 2 SMA Female bulkheads.
JRE D3-PEM-LAN10G-USB2 specifications
- Part Number
- D3-PEM-LAN10G-USB2
- SMA Connectors
- 2 SMA Female bulkhead connectors
- Filtered Interface
- 1 Dual Filtered interface with USB2 and RJ-45 10G Ethernet filters
- Power Entry Module
- 1 PEM-1 Filtered mains power entry module
- Plate Size
- Type "D" I/O plate
- Compatible Enclosures
- Any JRE Test chamber that uses Type "D" I/O plate (e.g. JRE 1724A)
JRE D3-PEM-LAN10G-USB2 overview
I use this mixed-speed setup when LAN-10G serves the network link while USB2 serves the device connection. The plate combines those paths, adds filtered mains entry, and reserves two SMA bulkheads for the RF side of the test.
- 1 Dual Filtered interface with USB2 and RJ-45 10G Ethernet filters
- LAN10G path discriminating differential data from common-mode RF
- 1 PEM-1 Filtered mains power entry module for power inside the chamber
- 2 SMA Female bulkhead connectors for RF stimulus or measurement
- In-stock Fast Track assembly, replaceable in the field with simple hand tools
At $1,220.00, the plate avoids custom lead time when this particular speed mix and power arrangement are already settled. Include the enclosure model with the quote request so JRE can confirm the Type D fit before the build is quoted. If either data link or the power plan changes, that is the point to move from this stocked combination to a custom plate.
