Fast Track Populated I/O Plate — JRE D3-PEM-LAN-USB2
Type D Fast Track plate with USB2 and RJ-45 filtering, a PEM-1 mains entry module, and 2 SMA Female bulkheads.
JRE D3-PEM-LAN-USB2 specifications
- Part Number
- D3-PEM-LAN-USB2
- SMA Connectors
- 2 SMA Female bulkhead connectors
- Filtered Interface
- 1 Dual Filtered interface with USB2 and RJ-45 Ethernet filters
- Power Entry
- 1 PEM-1 Filtered mains power entry module
- Plate Size
- Type "D" I/O plate
JRE D3-PEM-LAN-USB2 overview
When a test plan changes, I prefer changing the I/O plate rather than altering the enclosure body. This field-replaceable Type D option arrives populated with mains power, USB2, Ethernet, and two SMA paths for RF stimulus or measurement.
- 1 Dual Filtered interface combining USB2 and RJ-45 Ethernet filters
- 1 PEM-1 Filtered mains power entry module for powering the internal setup
- 2 SMA Female bulkhead connectors for RF signals across the plate
- Purpose-built filtered crossings for the USB2, LAN, and mains connections
- In-stock Fast Track plate, field-replaceable with simple hand tools
At $1,110.00, this configuration makes sense when the DUT needs the whole set rather than one data interface in isolation. The populated plate can join an in-stock enclosure for delivery in days. If the test changes later, swap the Type D plate in the field rather than altering the enclosure body.
