Fast Track Populated I/O Plate — JRE B3-PEM-LAN-USB3
Type B plate with 1 USB3-1/RJ-45 dual interface, 1 PEM-1 power module, and 2 SMA Female bulkheads.
JRE B3-PEM-LAN-USB3 specifications
- Part Number
- B3-PEM-LAN-USB3
- SMA Female bulkhead connectors
- 2
- Filtered interface
- 1 Dual filtered interface with USB3-1 and RJ-45 Ethernet Filters
- Power entry module
- 1 PEM-1 Filtered AC mains power entry module
- Plate size
- Type "B" I/O plate
- Compatible enclosures
- JRE 0612CLAM, JRE 0912, JRE 1724, JRE 1729, JRE 1812, JRE 2218
JRE B3-PEM-LAN-USB3 overview
The JRE B3-PEM-LAN-USB3 is a populated B-size I/O plate carrying USB3-1, RJ-45 Ethernet, filtered AC mains entry and two RF paths. All four functions arrive together on the populated plate.
- 1 dual filtered interface combines USB3-1 and RJ-45 Ethernet connections
- USB3-1 discriminates by mode: differential data passes while common-mode RF is low-pass filtered out
- 1 PEM-1 filtered AC mains power entry module brings power inside
- 2 SMA Female bulkhead connectors with dust caps provide the RF paths
- Type "B" plate format is replaceable in the field with simple hand tools
- In-stock Fast Track assembly can support delivery in days with an in-stock enclosure
The $1,225.00 price buys the populated standard assembly, not a blank starting point for later machining. I decide from the DUT's complete cable list; if one required crossing is absent, JRE can design, populate, mount, and final-test a custom plate instead.
