6 TERM FILT AC/DC
6-terminal Pi-style feedthrough filter rated for 20 Amps and 250VAC/100VDC.
Price
$138.00
published · no quote wall
6 TERM FILT AC/DC specifications
- Filter Type
- Pi style feedthru filter
- Terminal Count
- 6
- Outside Connection
- Screw terminals
- Inside Connection
- 1/4" fast-on connector lugs
- Max Current
- 20 Amps
- Max Voltage
- 250VAC / 100VDC
- Filter Capacitance
- 2500pF
- Attenuation
- Greater than 80 dB at 500 MHz and beyond
6 TERM FILT AC/DC overview
This 6-terminal Pi-style feedthrough filter uses screw terminals outside and 1/4-inch fast-on connector lugs inside. It is rated for 20 Amps at up to 250VAC/100VDC, with 2500pF capacitance and greater than 80 dB attenuation at 500 MHz and beyond.
