2 TERM FILT AC/DC
2-terminal Pi-style feedthrough filter rated for 20 Amps and 250VAC/100VDC.
Price
$88.00
published · no quote wall
01 Specifications
- Isolation
- greater than 80dB attenuation at 500MHz and beyond
- Terminals
- 2
- Filter type
- Pi style feedthru
- Outside connector
- screw terminals
- Inside connector
- 1/4″ fast-on connector lugs
- Max current
- 20Amps
- Max voltage
- 250VAC/100VDC
- Filter capacitance
- 2500pF
- Attenuation
- greater than 80dB at 500MHz and beyond
02 Overview
This 2-terminal Pi-style feedthrough filter uses screw terminals outside and 1/4-inch fast-on connector lugs inside. It is rated for 20 Amps at up to 250VAC/100VDC, with 2500pF capacitance and greater than 80dB attenuation at 500MHz and beyond.
