Magnetic Switch for door — JRE MS-1
Magnetic SPST-NO door switch rated for 200VDC, 140VAC, and 0.5 Amps.
Price
$90.00
published · no quote wall
JRE MS-1 specifications
- Contact configuration
- SPST-NO
- Contact type
- Normally Open magnetic reed switch
- Voltage rating DC
- 200VDC
- Voltage rating AC
- 140VAC
- Current rating
- 0.5 Amps
- Closed contact resistance
- <0.3 ohms
JRE MS-1 overview
The JRE MS-1 is a magnetic reed switch installed on a test chamber door to indicate closure. Its SPST-NO contact is rated at 200VDC, 140VAC, and 0.5 Amps, with closed-contact resistance below 0.3 ohms.
