Fast Track Populated I/O Plate — JRE C3-PEM-LAN2-USB2-2

At $1,920.00, I would first compare this production plate with a comparable custom layout. Its fixed population combines dual USB2, dual Ethernet, mains entry, and RF bulkheads when that complete connector set matches the DUT.

• 1 Dual USB2 filtered interface gives the DUT setup two USB paths through the wall.
• USB2 and LAN channels use low-pass filtering, the appropriate approach for these signal families.
• 1 Dual Filtered LAN Ethernet interface carries the paired wired-network connections.
• 1 PEM-1 Filtered mains power entry module handles the AC mains crossing.
• 4 Female SMA bulkhead connectors with dust caps carry RF signals into and out of the chamber.
• Type "C" format can be replaced in the field with simple hand tools.
• Fast Track population supports delivery in days when matched with an in-stock enclosure.

The standardized population costs less than having the same arrangement made as a custom plate. A mismatch on even one interface is a reason to choose another configuration. When the set is right and an in-stock enclosure is available, Fast Track population can support delivery in days.
